Name: Recycling Hazardous Waste Production Line for waste management solutions
Brand: Zhengzhou Hengyang Industrial Co., Ltd
SKU: Forno
Price: 65,350.00 USD
Availability: InStock

Casa. > prodotti > EAF Dust Recycling >

Recycling Hazardous Waste Production Line for waste management solutions

Recycling Hazardous Waste Production Line

Hazardous Waste Production Line

Luogo di origine:

Cina

Marca:

hengyang

Certificazione:

ISO9001

Numero di modello:

Forno

Documento:

EAF Dust Recycling Rotary K...ln.pdf

Contattaci

Chiedi un preventivo

Recycling Hazardous Waste Production Line for waste management solutions

Dettagli del prodotto

Voltaggio:

fino allo standard locale dei clienti

Garanzia:

12 mesi

OEM:

accettare

Colore:

Personalizza

Funzione:

Produzione ZinO

Termini di pagamento e di spedizione

Quantità di ordine minimo

Prezzo

35000-95700USD/set

Imballaggi particolari

Negociato

Tempi di consegna

25-40 giorni

Termini di pagamento

T/T

Capacità di alimentazione

30 set/mese

PRODOTTI RELATIVI

Acid Leaching in EAF Dust Recycling

Ottieni il miglior prezzo

Waelz Kiln Technology of EAF Dust Extracting ZinO for Industrial Recycling Solutions

Ottieni il miglior prezzo

Recycling Hazardous Waste Production Line for waste management solutions

Ottieni il miglior prezzo

Contattaci

Contatta ora

Descrizione del prodotto

EAF dust is a byproduct generated during the recycling of scrap iron in electric arc furnaces (EAF). It is considered industrial waste and contains heavy metals, as well as valuable metals like zinc and iron powder.

During the EAF process, the high temperatures required to melt the feed material produce a zinc byproduct (EAF dust) that leaves the furnace along with the off-gases. The gases are filtered and the EAF dust is collected in bag houses.

The EAF dust waste steam is considered a hazardous material due to the potential for the heavy metals to leach into the ground, contaminating ground water and sewage systems.

The EAF dust generated by steel mills can be recycled in an economically viable way using the Waelz Kiln technology. The recycling process is part of the larger steel industry loop that allows the reuse of two important natural resources - zinc and iron. Recycling Hazardous Waste Production Line for waste management solutions 0

Kiln Technical Details

Specification Model (m)	The size of the kiln			Yield (t/h)	Speed (r/min)	Electrical power (kw)	Weight (t)	Remarks
Specification Model (m)	Diameter (m)	Length (m)	Gradient (%)	Yield (t/h)	Speed (r/min)	Electrical power (kw)	Weight (t)	Remarks
φ1.4×33	1.4	33	3	0.9-1.3	0.39-3.96	18.5	47.5	----
φ1.6×36	1.6	36	4	1.2-1.9	0.26-2.63	22	52	----
φ1.8×45	1.8	45	4	1.9-2.4	0.16-1.62	30	78.2	----
φ1.9×39	1.9	39	4	1.65-3	0.29-2.93	30	77.59	----
φ2.0×40	2	40	3	2.5-4	0.23-2.26	37	119.1	----
φ2.2×45	2.2	45	3.5	3.4-5.4	0.21-2.44	45	128.3	----
φ2.5×40	2.5	40	3.5	9.0-10.5	0.44-2.44	55	149.61	----
φ2.5×50	2.5	50	3	6.25-7.4	0.62-1.86	55	187.37	----
φ2.5×54	2.5	54	3.5	6.9-8.5	0.48-1.45	55	196.29	----
φ2.7×42	2.7	42	3.5	10.0-11.0	0.10-1.52	55	198.5	----
φ2.8×44	2.8	44	3.5	12.5-13.5	0.437-2.18	55	201.58	Preheater kiln
φ3.0×45	3	45	3.5	12.8-14.5	0.5-2.47	75	210.94	----
φ3.0×48	3	48	3.5	25.6-29.3	0.6-3.48	100	237
φ3.0×60	3	60	3.5	12.3-14.1	0.3-2	100	310	----
φ3.2×50	3.2	50	4	40.5-42	0.6-3	125	278
