Name: Graphite Ore Beneficiation Modified Grinding And Pre-Screening Process Plant
Brand: Zhengzhou Hengyang Industrial Co., Ltd
SKU: HC-609
Price: 66,150.00 USD
Availability: InStock

Casa. > prodotti > Impianto di lavorazione minerale >

Graphite Ore Beneficiation Modified Grinding And Pre-Screening Process Plant

Modified Grinding Plant

Graphite Ore Beneficiation Plant

Pre-Screening Grinding Plant

Marca:

Hengyang

Certificazione:

ISO9001

Numero di modello:

HC-609

Contattaci

Chiedi un preventivo

Graphite Ore Beneficiation Modified Grinding And Pre-Screening Process Plant

Dettagli del prodotto

Name:

Graphite Ore Beneficiation Using a Modified Grinding and Pre-Screening Process

Application:

Graphite

Process:

Pressure Leaching and Flotation

Capacity:

50-300t/d

OEM:

Termini di pagamento e di spedizione

Quantità di ordine minimo

Prezzo

56200-76100

Imballaggi particolari

Negoziato

Tempi di consegna

20-40 giorni

Termini di pagamento

T/T

Capacità di alimentazione

270 insiemi/mese

PRODOTTI RELATIVI

Lavoratori di impianti di rettifica della grafite

Ottieni il miglior prezzo

Processo di estrazione del grafite

Ottieni il miglior prezzo

Mineral Processing Plant High Purity Graphite Using Comminution Pressure Leaching And Flotation

Ottieni il miglior prezzo

Graphite Production Process Plant 50-350t/d Capacity

Ottieni il miglior prezzo

Contattaci

86-371-56611369

Contatta ora

Descrizione del prodotto

Graphite has flake graphite, expandable graphite, synthetic graphite, surface-enhanced flake graphite, nature graphite, pure graphite, amorphous graphite, artificial graphite, graphite nanoplatelets, petroleum coke, etc.

The graphite is in the form of crystalline flakes or blades, black or steel gray, and is mainly contained in feldspar, quartz or diopside, and tremolite particles. It has an obvious directional arrangement and is consistent with the layer direction. Graphite flakes are generally (1.0~2.0)X(0.5~1.0)mm, the thickness of the flakes is 0.02~0.05mm, the largest scale can reach 4~5mm, and the smallest is (0.5~1.0)x(0.25~0.5)mm. The graphite content is generally 3%~10%, and individuals can reach 20%.

Graphite ore contains a large number of impurity minerals, especially flake graphite ore whose grade is very low and must be enriched by ore beneficiation.

Flotation is the main method of graphite beneficiation, but the flotation of flake graphite is different from amorphous graphite. In the process of flake graphite beneficiation, care should be taken to protect the large graphite flakes.

The grade of flake graphite is generally 3%~15%, but flake graphite has good floatability. In the process of beneficiation, to protect the graphite flakes, multi-stage grinding and multi-stage separation are required. Through screening (or hydro cyclone classification), the dissociated large flake graphite can be separated in time to avoid repeated abrasion. In flotation, kerosene, diesel, heavy oil, sulfonate, sulfate, phenols, hydroxy acids, etc. are commonly used as collectors, and No. 2 oil, No. 4 oil, ether alcohol, and butyl ether oil are used as foaming agents. The general process flow is crude ore coarse crushing-fine crushing-coarse grinding-flotation-concentrate regrind-dehydration-drying-grading-packaging.

Which machines for graphite? which depends on what production you needed from graphite. Such as need a bead mill for graphene, we exported Nano pin-type bead mill to Korea, and Russia, etc. also can be installed high shear emulsifier and chemical reactor. 1, PIN type BEAD MILL, grinding into D90=3um from D50=25um for 5hours 2, Ribbon Blender for the pre-mixing machine, customized capacity and functions according to graphite. 3, also customized chemical reactors and high shear emulsifier tank

Graphite Ore Beneficiation Modified Grinding And Pre-Screening Process Plant 0

Hengyang Company is one of company in China that offers a one stop shopping concept for graphite projects covering the whole value chain from drill core analyses up to process development for obtaining saleable graphite products, sample production and engineering of a processing plant. The main stages of the process may be summarized as:

– Pre-processing

– Physical processing

– Chemical and thermal processing

– Refinement

Graphite Ore Beneficiation Modified Grinding And Pre-Screening Process Plant 1
